Side approach mechanism SAM-H7-16-150N-020-060-S Item 45680

Downloads
Conformation of RoHS compliance (EN|PDF)
Product datasheet (EN|pdf)
Document (45680__Kundenzeichnung.PDF)
CAD file (INGUN_45680.STEP)
Document (45680_Montagezeichnung.PDF)
Choose version
SAM-H7-16-150N-020-060-S (45680) INGUN SELECTION
SAM-H7-16-150N-020-060-S (45680) INGUN SELECTION SAM-H7-20-150N-020-077 (106220)
Here you can optionally configure a new variant:
Technical data
General data
Product group : Side approach mechanism (SAM)
Series : SAM-H
Accessory type : Customising accessory
Contact stroke generation : Stroke controlled
Weight : 0.14 kg
Min. temperature : - 5 °C
Max. temperature : + 60 °C
Technical data
Max. contact stroke force : 150 N
Max. contact stroke : 16 mm
Contact stroke detection : -
Max. operating stroke : 7 mm
Max. lever arm length : 60 mm
Max. torque : 1.5 Nm
Outer dimensionS (WxDxH) : 20 x 60 x 40 mm
Compatible with
Exchangeable kits version : Standard # ESD # RF
Manual test fixtures (MA) : MA 20xx
Pneumatic test fixtures (PA) : PA xxxx
Vacuum test fixtures (VA) : VA xxxx
MA exchangeable kits (ATS MA) : ATS MAxx
