Board marker probe ME-E-R2,0-12-080-S12V Item 38371
Board marker probe ME-E-R2,0-12-080-S12V Item 38371
Please log in to show the price
Login
The prices listed in the scale are displayed rounded, therefore deviation in the total price is possible.
Shipping costs
* The prices are rounded to two decimal places.
Technical data
| Product group : | Board marker probes (ME) |
|---|---|
| Series : | ME-E |
| Version : | Electrical |
| Accessory type : | Customising accessory |
| Outer dimensions (TxL) : | 12 x 80 mm |
| Outer thread : | M12 x 1 |
| Lock nut width across flats : | 14 mm |
| Marking type : | Circle |
| Approx. marking Ø : | 2 mm |
| Surface material : | Hard / soft |
| Weight : | 0.05 kg |
| Min. temperature : | - 20 °C |
| Max. temperature : | + 65 °C |
| RoHS-compliant : | RoHS-3;6c |
| Recommended working stroke : | 1.5 mm |
|---|---|
| Recommended marking impulse : | 1.0 s |
| Maximum stroke (ME) : | 2 mm |
| Approx. compression at working stroke : | 3 N |
| Marking tip : | Scratching engraver |
| Engraver material : | Solid carbide |
| Approx. engraver hardness : | 1600 HV |
| Drive : | Electric gear motor |
| Motor connection via : | Plug connector |
| Rated voltage : | 12 V DC |
| Rated output : | 0.75 W |
| No-load current : | 3.68 mA |
| Starting current : | 106 mA |
| Connecting resistance : | 114 Ohm |
| Max. load current : | 81 mA |
| Max. torque : | 54 mNm |
| Approx. idle speed : | 180 U/min |
| Noise emission : | Not relevant |
| Manual test fixtures (MA) : | MA 20xx |
|---|---|
| Pneumatic test fixtures (PA) : | PA xxxx |
| Vacuum test fixtures (VA) : | VA xxxx |
| MA exchangeable kits (ATS MA) : | ATS MAxx, ATS MAxxxx |
| VA exchangeable kits (ATS VA) : | VIN 423 # VIN 2040 |
| PA exchangeable kits (ATS PA) : | ATS PAZxxx |
