Transfer field TF-P-SI-030-L Item 48740
Transfer field TF-P-SI-030-L Item 48740
Please log in to show the price
Login
The prices listed in the scale are displayed rounded, therefore deviation in the total price is possible.
Shipping costs
* The prices are rounded to two decimal places.
Technical data
| Product group : | Transfer fields |
|---|---|
| Series : | TF-SI |
| Type : | Kontaktmodul |
| Version : | Device under test (DUT) side |
| Accessory type : | Customising accessory |
| Scope of delivery : | Fully loaded with KT-254 L3 E02 |
| Width : | 10 mm |
| Height : | 15 mm |
| Weight : | 0.02 kg |
| Min. temperature : | + 10 °C |
| Max. temperature : | + 60 °C |
| RoHS-compliant : | RoHS-3;6c |
| Connection : | Solder connection |
|---|---|
| Number of poles : | 30 |
| Installation grid : | 2.54 mm |
| Length : | 65.5 mm |
| Outer dimensionS (WxDxH) : | 65.5 x 10 x 15 mm |
| Exchangeable kits version : | No limitations |
|---|---|
| MA exchangeable kits (ATS MA) : | ATS MAxx |
| For dual-stage contacting : | Yes |
