產品資訊 "BCP-696 360 2200 A 150004-56"
- 适用于 4680 圆柱电芯与棱柱电芯的接触解决方案
- Current rating upto 200 A on Al DUT with temperaturer rise dT ≤ 20 K ; max. current rating of 450 A on high conducting materials like copper alloys
- Designed for a range of cell contacting applications such as Formation, Charging and DC-IR measurement
- Continuous plunger system with minimal internal resistance Ri typical < 0.5 mΩ
- 带柔性电缆连接的简易法兰安装
- Dipole Design provided with 5N measuring contact for precise voltage measurements
- 电压传感器易于连接：可焊接或压接端子安装
Accedere
产品详情
- 适用于 4680 圆柱电芯与棱柱电芯的接触解决方案
- Current rating upto 200 A on Al DUT with temperaturer rise dT ≤ 20 K ; max. current rating of 450 A on high conducting materials like copper alloys
- Designed for a range of cell contacting applications such as Formation, Charging and DC-IR measurement
- Continuous plunger system with minimal internal resistance Ri typical < 0.5 mΩ
- 带柔性电缆连接的简易法兰安装
- Dipole Design provided with 5N measuring contact for precise voltage measurements
- 电压传感器易于连接：可焊接或压接端子安装
