Product information sheets
Product information "SW-GKS-912 A"
| Compatible test probe(s) / receptacle(s): | 401 GKS-204, GKS-422, GKS-912 |
|---|---|
| Max. tip diameter: | 3 mm [.118 in] |
| Min. tip diameter: | 0 mm [0 in] |
| Product group: | Insertion tools (SW) |
| RoHS-compliant: | Yes |
| Series: | SW-GKS |
| Test probe installation type: | Plug-in |
| Tool for receptacle (KS): | No |
| Tool for test probe (GKS): | Yes |
| Tool version: | Rigid |
Login
Other products in this series:
Technical data
General data
- Product group: Insertion tools (SW)
- Series: SW-GKS
- RoHS-compliant: Yes
- Compatible test probe(s) / receptacle(s): GKS-422
- Max. tip diameter: 3 mm [.118 in]
- Compatible test probe(s) / receptacle(s): GKS-912
- Tool for test probe (GKS): Yes
- Min. tip diameter: 0 mm [0 in]
- Compatible test probe(s) / receptacle(s): 401 GKS-204
- Tool for receptacle (KS): No
- Tool version: Rigid
- Test probe installation type: Plug-in
