Product information "KB-P-SI-096-4A-097-016-1,1"
- Suitable for WS KEYSIGHT/i7090 inline interchangeable kit to equip the test system interface
- Equipped with INGUN contact terminals KT-158
- Uniformly parallel wire-wrap posts
- Consistently low contact resistances and replicable measured values
- High contact reliability and transmission quality
| Accessory type: | Customising accessories |
|---|---|
| Bestückung: | 96 x KT-158 (posts) |
| Centring pin: | No |
| Connection: | Wire-wrap posts |
| Inline interchangeable kits (WS): | WS Keysight/i7090 |
| Max. temperature: | 45 °C [113 °F] |
| Min. line cross-section: | 0.25 mm² [.00038 in²] |
| Min. temperature: | 10 °C [50 °F] |
| Number of poles: | 96 |
| Product group: | Interface blocks (SB) |
| RoHS-compliant: | Yes |
| Series: | SB-SI |
| Type: | Signal block |
| Typical resistance (Ri) of one GKS: | 5 mOhm |
| Version: | WS interface |
| Weight: | 0.02 kg [.044 lbs] |
Login
Product Details
- Suitable for WS KEYSIGHT/i7090 inline interchangeable kit to equip the test system interface
- Equipped with INGUN contact terminals KT-158
- Uniformly parallel wire-wrap posts
- Consistently low contact resistances and replicable measured values
- High contact reliability and transmission quality
Other products in this series:
Technical data
Technical data
- Number of poles: 96
- Centring pin: No
- Min. line cross-section: 0.25 mm² [.00038 in²]
- Connection: Wire-wrap posts
Electrical data
- Typical resistance (Ri) of one GKS: 5 mOhm
General data
- Accessory type: Customising accessories
- Min. temperature: 10 °C [50 °F]
- Max. temperature: 45 °C [113 °F]
- Type: Signal block
- RoHS-compliant: Yes
- Product group: Interface blocks (SB)
- Bestückung: 96 x KT-158 (posts)
- Version: WS interface
- Series: SB-SI
- Weight: 0.02 kg [.044 lbs]
Compatible with
- Inline interchangeable kits (WS): WS Keysight/i7090
