Product information "GKS-181 354 080 A 1503"
| -: | 10.5 mm [.413 in] |
|---|---|
| Adjustable installation height: | no |
| Barrel diameter: | 1 mm [.039 in] |
| Collar height: | 03 |
| Compatible connector(s): | SE-111 |
| Contacting from: | Pad, Post, Pin |
| Current load capacity / rated current: | 3 A |
| Grid: | 1.27 mm [50 mil] |
| Installation type: | Plug-in |
| Magnetic: | yes |
| Max. temperature: | 80 °C [176 °F] |
| Maximum stroke: | 7.5 mm [.295 in] |
| Min. temperature: | -40 °C [-40 °F] |
| Non-rotating: | no |
| Product group: | ICT / FCT (in-circuit test and function test |
| Quick-exchange system: | no |
| RoHS-compliant: | yes |
| Series: | GKS-181..0x |
| Spring force at working stroke: | 1.5 N [5.39 ozf] |
| Spring pre-load: | 0.28 N [1 ozf] |
| Sub-product group: | Fine-pitch |
| Temperaturbereich: | -40 – 80 °C [-40 – 176 °F] |
| Tip diameter: | 0.8 mm [.031 in] |
| Tip style: | 54 4-point crown, special length |
| Tip style material: | 3 CuBe |
| Tip style surface: | A gold |
| Total length: | 39.8 mm [1.56 in] |
| Type of test probe connection: | Plug |
| Typical resistance (Ri): | 20 mOhm |
| Working stroke: | 5.5 mm [.216 in] |
