Product information "FB-2VE-VA4060"
| Accessory type: | Customising accessories |
|---|---|
| Height: | 60 mm [2.36 in] |
| Length: | 462 mm [18.1 in] |
| Max. temperature: | 60 °C [140 °F] |
| Max. voltage: | 12 VDC |
| Min. temperature: | 10 °C [50 °F] |
| Outer dimensionS (WxDxH): | 568 x 462 x 60 mm [22.3 x 18.1 x 2.36 in] |
| Product group: | Functional units |
| RoHS-compliant: | Yes |
| Scope of delivery: | Unassembled |
| Series: | FB-VAxxxx |
| Type: | Electric shifting unit |
| Useable area (WxD): | 530 x 430 mm [20.8 x 16.9 in] |
| Vacuum test fixtures (VA): | VA 4060 |
| Version: | Dual-stage |
| Weight: | 0.8 kg [1.76 lbs] |
| Width: | 568 mm [22.3 in] |
Login
Other products in this series:
Technical data
General data
- Max. temperature: 60 °C [140 °F]
- Version: Dual-stage
- Accessory type: Customising accessories
- Scope of delivery: Unassembled
- Weight: 0.8 kg [1.76 lbs]
- Type: Electric shifting unit
- Min. temperature: 10 °C [50 °F]
- Product group: Functional units
- RoHS-compliant: Yes
- Height: 60 mm [2.36 in]
- Series: FB-VAxxxx
- Width: 568 mm [22.3 in]
Technical data
- Length: 462 mm [18.1 in]
- Outer dimensionS (WxDxH): 568 x 462 x 60 mm [22.3 x 18.1 x 2.36 in]
- Max. voltage: 12 VDC
- Useable area (WxD): 530 x 430 mm [20.8 x 16.9 in]
Compatible with
- Vacuum test fixtures (VA): VA 4060
