Downloads
Product information sheets
Product information "DW-20-120"
| Product group: | Torque wrench (DW) |
|---|---|
| RoHS-compliant: | Yes |
| Screw-in torque: | 20 – 120 cNm [1.77 – 10.6 lbf·in] |
| Screw-in torque max.: | 120 cNm [10.6 lbf·in] |
| Screw-in torque min.: | 20 cNm [1.77 lbf·in] |
| Series: | DW |
| Test probe installation type: | Screw-in |
| Tool for receptacle (KS): | No |
| Tool for test probe (GKS): | Yes |
| Tool version: | Adjustable |
Login
Other products in this series:
Technical data
General data
- Screw-in torque max.: 120 cNm [10.6 lbf·in]
- Screw-in torque min.: 20 cNm [1.77 lbf·in]
- Product group: Torque wrench (DW)
- Series: DW
- Screw-in torque: 20 – 120 cNm [1.77 – 10.6 lbf·in]
- RoHS-compliant: Yes
- Tool version: Adjustable
- Tool for test probe (GKS): Yes
- Test probe installation type: Screw-in
- Tool for receptacle (KS): No
