Product information "BIT-T-912 M"
| Compatible test probe(s) / receptacle(s): | 042 T-888, T-912 |
|---|---|
| Max. tip diameter: | 5 mm [.196 in] |
| Min. tip diameter: | 0 mm [0 in] |
| Product group: | Bit inserts (BIT) |
| RoHS-compliant: | Yes |
| Screw-in torque: | 3 – 5 cNm [.265 – .442 lbf·in], 10 – 20 cNm [.885 – 1.77 lbf·in] |
| Screw-in torque max.: | 20 cNm [1.77 lbf·in] |
| Screw-in torque min.: | 3 cNm [.265 lbf·in] |
| Series: | BIT-T |
| Test probe installation type: | Screw-in |
| Tool for receptacle (KS): | No |
| Tool for test probe (GKS): | Yes |
| Tool version: | Rigid |
Login
Other products in this series:
Technical data
General data
- Screw-in torque max.: 20 cNm [1.77 lbf·in]
- Screw-in torque min.: 3 cNm [.265 lbf·in]
- Product group: Bit inserts (BIT)
- Compatible test probe(s) / receptacle(s): T-912, 042 T-888
- Series: BIT-T
- Tool for receptacle (KS): No
- Tool for test probe (GKS): Yes
- Test probe installation type: Screw-in
- Min. tip diameter: 0 mm [0 in]
- Max. tip diameter: 5 mm [.196 in]
- Tool version: Rigid
- Screw-in torque: 3 – 5 cNm [.265 – .442 lbf·in], 10 – 20 cNm [.885 – 1.77 lbf·in]
- RoHS-compliant: Yes
