Product information "FB-ALS-VA207x"
- Reliable dissipation of electrostatic discharges that occur as a result of potential differences
- Quick, easy installation
| Accessory type: | Customising accessories |
|---|---|
| Bestückung: | GKS-414-0007 |
| Diameter: | 3 mm [.118 in] |
| Interchangeable kits (WS): | WS/KEYSIGHT/i3070 |
| Length: | 40.8 mm [1.6 in] |
| Max. temperature: | 60 °C [140 °F] |
| Min. temperature: | 10 °C [50 °F] |
| Product group: | Functional units |
| RoHS-compliant: | Yes |
| Scope of delivery: | Unassembled |
| Series: | FB-VAxxxx |
| Stroke: | 10 mm [.393 in] |
| Type: | ESD discharge contact |
| Vacuum test fixtures (VA): | VA 2070, VA 3070 |
| Version: | Single-stage contacting |
| Weight: | 0.01 kg [.022 lbs] |
Login
Product Details
- Reliable dissipation of electrostatic discharges that occur as a result of potential differences
- Quick, easy installation
Other products in this series:
Technical data
General data
- Max. temperature: 60 °C [140 °F]
- Version: Single-stage contacting
- Accessory type: Customising accessories
- Scope of delivery: Unassembled
- Min. temperature: 10 °C [50 °F]
- Product group: Functional units
- RoHS-compliant: Yes
- Type: ESD discharge contact
- Series: FB-VAxxxx
- Bestückung: GKS-414-0007
- Weight: 0.01 kg [.022 lbs]
Compatible with
- Vacuum test fixtures (VA): VA 2070
- Vacuum test fixtures (VA): VA 3070
- Interchangeable kits (WS): WS/KEYSIGHT/i3070
Technical data
- Stroke: 10 mm [.393 in]
- Length: 40.8 mm [1.6 in]
- Diameter: 3 mm [.118 in]
